1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing

I'm Online Chat Now

1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing

1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing

Large Image :  1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing

Product Details:
Place of Origin: Henan, China
Brand Name: Recycle
Payment & Shipping Terms:
Price: $8,000.00/sets >=1 sets

1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing

Description
Condition: New Plastic Type: PVC, PET, ABS, PP/PE, PE, PP
Machine Type: Plastic Crusher Max.Production Capacity (kg/h): 5000
Production Capacity (kg/h): 1000 - 5000 Kg/h Use: Waste Plastic Crusher
Voltage: 380V 50HZ Dimension(L*W*H): 1600*1680*2080mm
Power (kW): 37 Weight (T): 2.3
Warranty: 1.5 Years, 12 Months Applicable Industries: Manufacturing Plant, Retail, Other
Key Selling Points: Multifunctional Showroom Location: Egypt, Turkey, Viet Nam, Brazil, Peru, Indonesia, India, Mexico, Russia, Spain, Thailand, South Korea, Chile, UAE, Colombia, Malaysia, Australia
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1.5 Years Core Components: Motor, Engine, Other
Product Name: New Design Factory Sale Plastic Shredder/Plastic Crusher Advantage: High Efficiency Low Cost
Blades Material: 9CrSi/D2/SKD-11/ DC53/Customized Keyword: Plastic Shredder Grinder Crusher Machine
Raw Material: PET. PE. PVC Etc Feature: Multi-function
Type: Automatic Function: Crushing Scrap Material
Motor: SIMENS/Customized

Plastic Crusher PET Bottle Crusher Machine Plastic Crushing Machine
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 0

Customer Case
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 1
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 2

Suitable Raw Materials
1. All kinds of hollow containers: plastic beverage cans, plastic buckets,iron drums, packing boxes,packing drums.

2. Used household appliances: TV, washing machine, refrigerator shell

3. Pipe material: large pipe, pipe fitting and PE pipe.

4. Used templates: wooden pallets, plastic pallets and forklifts

5. Used tires: car tires, truck tires

6. Scrap metal: automobile housing, aluminum alloy, scrap cast aluminum parts, engine housing, lead and steel plates with thickness below 5mm

7. Cooking garbage, living garbage, RDF derivative,medical waste, biological orange pole,garden garbage

8. Glue head material, paper mill rope
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 3

Main Structures
1. Shaft,moving blades, fixed blades, reducer, motors, feeding hopper, discharge port, electric control cabinet, control panel, screen, roller, knives holder, ect.

2. After shredding, the dimension of most large plastic or other material will reduce 30%,some material dimension after shredding can be up to 50%. (We have arranged many videos. Please contact us freely if you need.)
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 4
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 5
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 6

Technical Parameters
Model
600
800
1000
1200
Feed Inlet Size
600*320mm
820*600mm
1020*650mm
1200*1000mm
Rotating Diameter
φ270
φ420
φ420
φ700
Power
15KW 20HP
37KW
45KW 60IP
55KW
Rotation Speed
380 r/min
480 r/min
480 r/min
380 r/min
Voltage
380V 50HZ
380V 50HZ
380V 50HZ
380V  50HZ
Machine Size
1150*1500*1600mm
1600*1680*2080mm
2000*1800*2400mm
3000*1800*4000mm
Weight
660kg
2300kg
3500kg
6000kg
NOTE:

Our crusher has many models. According to material size and discharge size.

Recommend different equipment models. Please contact us for details.

1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 7
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 8
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 9

Customer Site
1000-5000 kg/h Production Capacity Plastic Crushing Machine for PET Bottle Crushing 10
Company Show
As one of the largest E-waste and Other Solid Waste Metal Recycling Machine manufacturer, our factory can provide the whole solutions. Perfect after-sales service is provided and CE certification is provided for all products.
We can dispatch engineers to overseas to help you with installation, training if you need.
Our Company has advanced technology, professional R&D team and perfect sales service system. Besides, we possess several patents and domestically-leading technologies. Our advanced equipment have been currently exported to USA, Spain, Turkey, Italy, Vietnam,Hungary, Australia, Korea, Malaysia, Singapore, India, Philippines, Ireland, Saudi Arabia, Dubai etc.
